Spectral phase control for optimized ionization injection in laser wakefield acceleration

M. P. Backhouse1,*, L. T. Dickson2,3, I. Moulanier2, F. Massimo2, C. C. Cobo1,4, F. Filippi5, C. Gustafsson6, E. Lofquist6, K. Svendsen6 et al.

M. J. V. Streeter1,7, R. J. Shalloo1,8, O. Vasilovici2, C. Ballage2, S. J. D. Dann9, C. D. Murphy4, Z. Najmudin1, S. Dobosz Dufrénoy10, O. Lundh6, and B. Cros2

  • *Contact author: michael.backhouse13@imperial.ac.uk
PDF

Phys. Rev. Accel. Beams 28, 121301 – Published 1 December, 2025

DOI: https://doi.org/10.1103/9gjq-htzn

Abstract

Generating narrow energy spread beams from laser wakefield accelerators with minimal dark current is important for many applications. We present an automated experiment using Bayesian optimization to control the laser spectral phase and focal position, achieving significant enhancement of the beam quality. Starting from a broadband spectrum, the optimized configuration achieved low-energy spread with negligible dark current above 20 MeV. Particle-in-cell simulations reveal that fine control over the laser spectral phase, particularly third-order dispersion, directly impacts the timing and localization of ionization injection due to its effect on the initial laser intensity envelope and its subsequent evolution. A positively skewed temporal profile enhances the plasma potential depth at the right location, enabling localized injection and reducing the energy spread and dark current. These findings highlight the impact of algorithmic optimization and the powerful, underutilized role of temporal shaping in beam quality control.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (40)

  1. T. Tajima and J. M. Dawson, Phys. Rev. Lett. 43, 267 (1979).
  2. F. Amiranoff, S. Baton, D. Bernard, B. Cros, D. Descamps, F. Dorchies, F. Jacquet, V. Malka, J. R. Marquès, G. Matthieussent, P. Miné, A. Modena, P. Mora, J. Morillo, and Z. Najmudin, Phys. Rev. Lett. 81, 995 (1998).
  3. E. Esarey, C. B. Schroeder, and W. P. Leemans, Rev. Mod. Phys. 81, 1229 (2009).
  4. A. Picksley, J. Stackhouse, C. Benedetti, K. Nakamura, H. E. Tsai, R. Li, B. Miao, J. E. Shrock, E. Rockafellow, H. M. Milchberg, C. B. Schroeder, J. van Tilborg, E. Esarey, C. G. R. Geddes, and A. J. Gonsalves, Phys. Rev. Lett. 133, 255001 (2024).
  5. S. P. D. Mangles, C. D. Murphy, Z. Najmudin, A. G. R. Thomas, J. L. Collier, A. E. Dangor, E. J. Divall, P. S. Foster, J. G. Gallacher, C. J. Hooker, D. A. Jaroszynski, A. J. Langley, W. B. Mori, P. A. Norreys, F. S. Tsung, R. Viskup, B. R. Walton, and K. Krushelnick, Nature (London) 431, 535 (2004).
  6. C. G. R. Geddes, C. Toth, J. van Tilborg, E. Esarey, C. B. Schroeder, D. Bruhwiler, C. Nieter, J. Cary, and W. P. Leemans, Nature (London) 431, 538 (2004).
  7. J. Faure, Y. Glinec, A. Pukhov, S. Kiselev, S. Gordienko, E. Lefebvre, J. P. Rousseau, F. Burgy, and V. Malka, Nature (London) 431, 541 (2004).
  8. T. P. Rowlands-Rees, C. Kamperidis, S. Kneip, A. J. Gonsalves, S. P. D. Mangles, J. G. Gallacher, E. Brunetti, T. Ibbotson, C. D. Murphy, P. S. Foster, M. J. V. Streeter, F. Budde, P. A. Norreys, D. A. Jaroszynski, K. Krushelnick, Z. Najmudin, and S. M. Hooker, Phys. Rev. Lett. 100, 105005 (2008).
  9. C. McGuffey, A. G. R. Thomas, W. Schumaker, T. Matsuoka, V. Chvykov, F. J. Dollar, G. Kalintchenko, V. Yanovsky, A. Maksimchuk, K. Krushelnick, V. Y. Bychenkov, I. V. Glazyrin, and A. V. Karpeev, Phys. Rev. Lett. 104, 025004 (2010).
  10. A. Pak, K. A. Marsh, S. F. Martins, W. Lu, W. B. Mori, and C. Joshi, Phys. Rev. Lett. 104, 025003 (2010).
  11. M. Chen, E. Esarey, C. B. Schroeder, C. G. R. Geddes, and W. P. Leemans, Phys. Plasmas 19, 033101 (2012).
  12. M. Mirzaie, S. Li, M. Zeng, N. A. M. Hafz, M. Chen, G. Y. Li, Q. J. Zhu, H. Liao, T. Sokollik, F. Liu, Y. Y. Ma, L. M. Chen, Z. M. Sheng, and J. Zhang, Sci. Rep. 5, 14659 (2015).
  13. A. Irman, J. P. Couperus, A. Debus, A. Köhler, J. M. Krämer, R. Pausch, O. Zarini, and U. Schramm, Plasma Phys. Controlled Fusion 60, 044015 (2018).
  14. M. Kirchen, S. Jalas, P. Messner, P. Winkler, T. Eichner, L. Hübner, T. Hülsenbusch, L. Jeppe, T. Parikh, M. Schnepp, and A. R. Maier, Phys. Rev. Lett. 126, 174801 (2021).
  15. S. Kneip, C. McGuffey, J. L. Martins, M. S. Bloom, V. Chvykov, F. Dollar, R. Fonseca, S. Jolly, G. Kalintchenko, K. Krushelnick, A. Maksimchuk, S. P. D. Mangles, Z. Najmudin, C. A. J. Palmer, K. T. Phuoc, W. Schumaker, L. O. Silva, J. Vieira, V. Yanovsky, and A. G. R. Thomas, Phys. Rev. ST Accel. Beams 15, 021302 (2012).
  16. R. Weingartner, S. Raith, A. Popp, S. Chou, J. Wenz, K. Khrennikov, M. Heigoldt, A. R. Maier, N. Kajumba, M. Fuchs, B. Zeitler, F. Krausz, S. Karsch, and F. Grüner, Phys. Rev. ST Accel. Beams 15, 111302 (2012).
  17. B. B. Pollock, C. E. Clayton, J. E. Ralph, F. Albert, A. Davidson, L. Divol, C. Filip, S. H. Glenzer, K. Herpoldt, W. Lu, K. A. Marsh, J. Meinecke, W. B. Mori, A. Pak, T. C. Rensink, J. S. Ross, J. Shaw, G. R. Tynan, C. Joshi, and D. H. Froula, Phys. Rev. Lett. 107, 045001 (2011).
  18. P. A. Walker et al., J. Phys. Conf. Ser. 874, 012029 (2017).
  19. S. Steinke, J. van Tilborg, C. Benedetti, C. G. R. Geddes, C. B. Schroeder, J. Daniels, K. K. Swanson, A. J. Gonsalves, K. Nakamura, N. H. Matlis, B. H. Shaw, E. Esarey, and W. P. Leemans, Nature (London) 530, 190 (2016).
  20. T. Kurz et al., Nat. Commun. 12, 2895 (2021).
  21. F. Albert and A. G. R. Thomas, Plasma Phys. Controlled Fusion 58, 103001 (2016).
  22. R. W. Assmann et al., Eur. Phys. J. Special Topics 229, 3675 (2020).
  23. R. J. Shalloo et al., Nat. Commun. 11, 6355 (2020).
  24. S. Jalas, M. Kirchen, P. Messner, P. Winkler, L. Hübner, J. Dirkwinkel, M. Schnepp, R. Lehe, and A. R. Maier, Phys. Rev. Lett. 126, 104801 (2021).
  25. F. Irshad, S. Karsch, and A. Döpp, Phys. Rev. Res. 5, 013063 (2023).
  26. F. Irshad, C. Eberle, F. M. Foerster, K. v. Grafenstein, F. Haberstroh, E. Travac, N. Weisse, S. Karsch, and A. Döpp, Phys. Rev. Lett. 133, 085001 (2024).
  27. C. K. Birdsall and A. B. Langdon, Plasma Physics via Computer Simulation (Taylor and Francis Group, London, 2004).
  28. B. Aurand, M. Hansson, L. Senje, K. Svensson, A. Persson, D. Neely, O. Lundh, and C.-G. Wahlström, Laser Part. Beams 33, 59 (2015).
  29. T. Audet, P. Lee, G. Maynard, S. D. Dufrénoy, A. Maitrallain, M. Bougeard, P. Monot, and B. Cros, Nucl. Instrum. Methods Phys. Res., Sect. A 909, 383 (2018).
  30. L. Dickson, C. Underwood, F. Filippi, R. Shalloo, J. B. Svensson, D. Guénot, K. Svendsen, I. Moulanier, S. D. Dufrénoy, C. Murphy et al., Phys. Rev. Accel. Beams 25, 101301 (2022).
  31. A. Buck, K. Zeil, A. Popp, K. Schmid, A. Jochmann, S. D. Kraft, B. Hidding, T. Kudyakov, C. M. S. Sears, L. Veisz, S. Karsch, J. Pawelke, R. Sauerbrey, T. Cowan, F. Krausz, and U. Schramm, Rev. Sci. Instrum. 81, 033301 (2010).
  32. B. Shahriari, K. Swersky, Z. Wang, R. P. Adams, and N. de Freitas, Proc. IEEE 104, 148 (2016).
  33. C. K. Williams and C. E. Rasmussen, Gaussian Processes for Machine Learning (MIT Press, Cambridge, MA, 2006), Vol. 2.
  34. F. Pedregosa, G. Varoquaux, A. Gramfort, V. Michel, B. Thirion, O. Grisel, M. Blondel, P. Prettenhofer, R. Weiss, V. Dubourg, J. Vanderplas, A. Passos, D. Cournapeau, M. Brucher, M. Perrot, and E. Duchesnay, J. Mach. Learn. Res. 12, 2825 (2011).
  35. A. Borzsonyi, A. P. Kovacs, and K. Osvay, Appl. Sci. 3, 515 (2013).
  36. R. Lehe, M. Kirchen, I. A. Andriyash, B. B. Godfrey, and J.-L. Vay, Comput. Phys. Commun. 203, 66 (2016).
  37. A. Lifschitz, X. Davoine, E. Lefebvre, J. Faure, C. Rechatin, and V. Malka, J. Comput. Phys. 228, 1803 (2009).
  38. J. L. Vay, Phys. Rev. Lett. 98, 130405 (2007).
  39. I. Moulanier, L. T. Dickson, C. Ballage, O. Vasilovici, A. Gremaud, S. Dobosz Dufrénoy, N. Delerue, L. Bernardi, A. Mahjoub, A. Cauchois, A. Specka, F. Massimo, G. Maynard, and B. Cros, Phys. Plasmas 30, 053109 (2023).
  40. I. Moulanier, L. T. Dickson, F. Massimo, G. Maynard, and B. Cros, J. Opt. Soc. Am. B 40, 2450 (2023).
