Experimental demonstration of accelerating a beam with a large transverse emittance ratio in the relativistic heavy ion collider for the electron-ion collider

Y. Luo*, B. Lepore, K. Mernick, T. Shrey, M. Blaskiewicz, C. Montag, G. Robert-Demolaize, and D. Xu

  • *Contact author: yluo@bnl.gov
PDF

Phys. Rev. Accel. Beams 29, L021001 – Published 17 February, 2026

DOI: https://doi.org/10.1103/7t62-5fvx

Abstract

The electron-ion collider (EIC), to be constructed at Brookhaven National Laboratory, will collide polarized high-energy electron beams with hadron beams, achieving luminosities of up to 1.0×1034  cm−2 s−1 in the center-of-mass energy range of 20–140 GeV. To reach such high luminosity, the EIC will employ small, flat beams at the interaction point. According to the design of the EIC hadron storage ring (HSR), hadron beams with a large transverse emittance ratio of 11:1 will be generated at the injection energy using an electron cooling technique and then accelerated to high energies for collisions. Accelerating hadron beams with such a large emittance ratio had never been demonstrated elsewhere—until our recent beam experiment at the relativistic heavy ion collider (RHIC). In this experiment, we successfully generated a large transverse emittance ratio of 13:1 with a gold-ion beam at 31 GeV/nucleon using stochastic cooling. We then accelerated this beam, with a transverse emittance ratio of 11:1, from 31 to 100 GeV/nucleon. Thanks to RHIC’s high-performance orbit, tune, and decoupling feedback systems, the large emittance ratio was well maintained throughout the 5-min-long acceleration process. This experiment fully validated the EIC/HSR design assumptions—namely, that large-emittance-ratio hadron beams can be generated at injection energy and then accelerated to high energies for collisions.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (26)

  1. J. Beebe-Wang et al., Electron-ion collider: Conceptual design report, Brookhaven National Laboratory, Jefferson Lab, www.bnl.gov/EC/files/EIC_CDR_Final.pdf (2021).
  2. A. Aprahamian et al., Reaching for the horizon: The 2015 long range plan for nuclear science, DOE/NSF Nuclear Science Advisory Panel (NSAC) Report, 2015, https://indico.bnl.gov/event/10974/contributions/46394/attachments/32983/52803/1296778.pdf.pdf.
  3. B. Wiik, HERA Proposal, Technical Report DESY-HERA Report, DESY-HERA 81-10, DESY, 1980 (unpublished), https://bib-pubdb1.desy.de/record/318643/files/DESY-HERA%2081-10.pdf.
  4. F. Willeke, Summary of the HERA proton-electron luminosity run 2004, Technical Report No. DESY-HERA-04-01, DESY-HERA, 2004.
  5. M. Harrison, T. Ludlam, and S. Ozaki, RHIC project overview, Nucl. Instrum. Methods Phys. Res., Sect. A 499, 235 (2003).
  6. S. Peggs, Flat beams in a 50 TeV hadron collider, https://epaper.kek.jp/pac97/papers/pdf/7P004.PDF.
  7. A. Piwinski, Intrabeam scattering, Standford Report No. HEAC 74, Standford Linear Accelerator Laboratory (SLAC), 1974.
  8. M. Martini, Intrabeam scattering in the ACOL-AA machines, Report No. CERN-PS. 84-9 (AA), CERN, 1984.
  9. J. D. Bjorken and S. K. Mtingwa, Intrabeam scattering, Part. Accel. 13, 115 (1983), https://cds.cern.ch/record/140304/?ln=en.
  10. D. Edwards and L. Teng, Parameterization of linear coupled motion, IEEE Trans. Nucl. Sci. 20, 885 (1973).
  11. G. Guignard, Betatron coupling and related impact of radiation, Phys. Rev. E 51, 6104 (1995).
  12. G. I. Budker, An effective method of damping particle oscillations in proton and antiproton storage rings, Sov. At. Energy 22, 438 (1967).
  13. S. Nagaitsev, D. Broemmelsiek, A. Burov, K. Carlson, C. Gattuso, M. Hu, T. Kroc, L. Prost, S. Pruss, M. Sutherland, C. W. Schmidt, A. Shemyakin, V. Tupikov, A. Warner, G. Kazakevich, and S. Seletskiy, Experimental demonstration of relativistic electron cooling, Phys. Rev. Lett. 96, 044801 (2006).
  14. A. V. Fedotov et al., Experimental demonstration of hadron beam cooling using radio-frequency accelerated electron bunches, Phys. Rev. Lett. 124, 084801 (2020).
  15. Y. S. Derbenev, On possibilities of fast cooling of heavy particle beams, AIP Conf. Proc. 253, 103 (1992).
  16. V. N. Litvinenko and Y. S. Derbenev, Coherent electron cooling, Phys. Rev. Lett. 102, 114801 (2009).
  17. D. Ratner, Microbunched electron cooling for high-energy hadron beams, Phys. Rev. Lett. 111, 084802 (2013).
  18. D. Cline et al., High energy electron cooling to improve the luminosity and lifetime in colliding beam machines, in Proceedings of the Particle Accelerator Conference 1979 (IEEE, New York, 1979); IEEE Trans. Nucl. Sci. 26, 3472 (1979).
  19. M. Gentner, R. Brinkmann, Y. Derbenev, D. Husmann, and C. Steier, On the possibilities of electron cooling for HERA, Nucl. Instrum. Methods Phys. Res., Sect. A 424, 277 (1999).
  20. H. Zhao, J. Kewisch, M. Blaskiewicz, and A. Fedotov, Ring-based electron cooler for high energy beam cooling, Phys. Rev. Accel. Beams 24, 043501 (2021).
  21. Y. Luo, D. Xu, M. Blaskiewicz, and C. Montag, Experimental demonstration of a large transverse emittance ratio 11:1 in the relativistic heavy ion collider for the electron-ion collider, Phys. Rev. Lett. 132, 205001 (2024).
  22. Y. Luo, D. Xu, I. Blackler, M. Blaskiewicz, A. Marusic, K. Mernick, C. Montag, and T. Shrey, Achieving a large transverse emittance ratio in the relativistic heavy ion collider: Beam experiments, analytical estimates, and implications for the electron-ion collider, Phys. Rev. Accel. Beams 28, 041002 (2025).
  23. M. Blaskiewicz, J. M. Brennan, and F. Severino, Operational stochastic cooling in the relativistic heavy-ion collider, Phys. Rev. Lett. 100, 174802 (2008).
  24. M. Blaskiewicz, J. M. Brennan, and K. Mernick, Three-dimensional stochastic cooling in the relativistic heavy ion collider, Phys. Rev. Lett. 105, 094801 (2010).
  25. Y. Luo, P. Cameron, A. Dellapenna, L. Hoff, A. Marusic, S. Peggs, C. Schultheiss, and R. Jones, Continuous measurement of global difference coupling using a phase-locked-loop tune meter in the relativistic heavy ion collider, Phys. Rev. ST Accel. Beams 9, 124001 (2006).
  26. P. Cameron, A. DellaPenna, L. Hoff, Y. Luo, A. Marusic, C. Schultheiss, S. Tepikian, M. Gasior, R. Jones, and C. Y. Tan, Simultaneous tune and coupling feedback in the relativistic heavy ion collider, and possible implications for the Large Hadron Collider commissioning, Phys. Rev. ST Accel. Beams 9, 122801 (2006).
