First beam test of an additively manufactured H-mode linac structure made from pure copper

Hendrik Hähnel1,*, Philipp Müller1, Jan Dominik Kaiser1, Adem Ateş1, Leonie Bauer1, Benjamin Dedić1, Ulrich Ratzinger1, Patrick Reichart2, Günther Dollinger2 et al.

Michael Mayerhofer2

  • *Contact author: haehnel@iap.uni-frankfurt.de
PDF

Phys. Rev. Accel. Beams 29, 060101 – Published 5 June, 2026

DOI: https://doi.org/10.1103/6fp9-dfyk

Abstract

This paper presents a high-power beam test of the first IH-type linac structure additively manufactured from pure copper performed in May 2025. The 433 MHz cavity with a total length of 20 cm has been tested up to 25 kW at a duty cycle of 2%, which corresponds to a cavity voltage of 0.86 MV with peak fields at the drift tubes reaching up to 68  MV/m without rf breakdown at full power. A 1.4 MeV proton beam from a Van de Graaff accelerator has been accelerated up to 2.212 MeV, demonstrating the effective acceleration voltage of 0.817 MV at full power. These high-power beam tests show performance on par with conventionally manufactured H-mode structures, paving the way for future linac structures benefiting from the advantages of additive manufacturing.
