Evolution of transversely asymmetric electron beams in hollow plasma channels

Siqin Ding1, Shiyu Zhou2,*, Fei Li2, Jianfei Hua1, and Wei Lu2,†

  • *Contact author: zhousy@ihep.ac.cn
  • †Contact author: weilu@ihep.ac.cn
PDF

Phys. Rev. Accel. Beams 29, 103601 – Published 7 October, 2026

DOI: https://doi.org/10.1103/13fz-y5wy

Abstract

Plasma wakefield acceleration in hollow plasma channels has emerged as a promising approach for positron acceleration, since an electron beam can drive wakes with a transversely uniform accelerating field and no intrinsic defocusing force for positrons. Recently, it was proposed that a transversely asymmetric electron beam can excite quadrupole-dominated wakefield in a hollow channel, enabling the formation of accelerating and focusing fields suitable for positrons [S. Zhou et al., Phys. Rev. Lett. 127, 174801 (2021)]. However, the self-consistent evolution and stability of such asymmetric drivers, which are crucial for sustaining a usable wake over long distances, remain insufficiently understood. In this work, we investigate the evolution of wakefield driven by asymmetric electron beams in hollow plasma channels using fully three-dimensional particle-in-cell simulations. We identify two distinct unstable scenarios: a reversal of quadrupole field polarity and continuous penetration of the driver into the plasma wall. By analyzing the transverse dynamics of the driver and the restoring forces provided by the channel ions, we establish simple physical criteria that ensure stable propagation. These results clarify the fundamental constraints governing asymmetric-driver evolution, provide practical guidance for realizing long-lived, quasisteady wakes in hollow plasma channels, and indicate that the scheme can preserve mm mrad-level normalized positron emittance.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (37)

  1. X. C. Lou, The circular electron positron collider, Nat. Rev. Phys. 1, 232 (2019).
  2. M. Benedikt, A. Blondel, P. Janot, M. Klein, M. Mangano, M. McCullough, V. Mertens, K. Oide, W. Riegler, D. Schulte, and F. Zimmermann, Future circular colliders, Annu. Rev. Nucl. Part. Sci. 69, 389 (2019).
  3. S. Michizono, The international linear collider, Nat. Rev. Phys. 1, 244 (2019).
  4. T. Tajima and J. M. Dawson, Laser electron accelerator, Phys. Rev. Lett. 43, 267 (1979).
  5. P. Chen, J. M. Dawson, R. W. Huff, and T. Katsouleas, Acceleration of electrons by the interaction of a bunched electron beam with a plasma, Phys. Rev. Lett. 54, 693 (1985).
  6. J. B. Rosenzweig, B. Breizman, T. Katsouleas, and J. J. Su, Acceleration and focusing of electrons in two-dimensional nonlinear plasma wake fields, Phys. Rev. A 44, R6189 (1991).
  7. W. Lu, C. Huang, M. Zhou, W. B. Mori, and T. Katsouleas, Nonlinear theory for relativistic plasma wakefields in the blowout regime, Phys. Rev. Lett. 96, 165002 (2006).
  8. I. Blumenfeld, C. E. Clayton, F.-J. Decker, M. J. Hogan, C. Huang, R. Ischebeck, R. Iverson, C. Joshi, T. Katsouleas, N. Kirby, W. Lu, K. A. Marsh, W. B. Mori, P. Muggli, E. Oz, R. H. Siemann, D. Walz, and M. Zhou, Energy doubling of 42 GeV electrons in a metre-scale plasma wakefield accelerator, Nature (London) 445, 741 (2007).
  9. A. Picksley, J. Stackhouse, C. Benedetti, K. Nakamura, H. E. Tsai, R. Li, B. Miao, J. E. Shrock, E. Rockafellow, H. M. Milchberg, C. B. Schroeder, J. van Tilborg, E. Esarey, C. G. R. Geddes, and A. J. Gonsalves, Matched guiding and controlled injection in dark-current-free, 10-GeV-class, channel-guided laser-plasma accelerators, Phys. Rev. Lett. 133, 255001 (2024).
  10. J. Götzfried, A. Döpp, M. F. Gilljohann, F. M. Foerster, H. Ding, S. Schindler, G. Schilling, A. Buck, L. Veisz, and S. Karsch, Physics of high-charge electron beams in laser-plasma wakefields, Phys. Rev. X 10, 041015 (2020).
  11. M. Litos et al., High-efficiency acceleration of an electron beam in a plasma wakefield accelerator, Nature (London) 515, 92 (2014).
  12. C. A. Lindstrøm, J. M. Garland, S. Schröder, L. Boulton, G. Boyle, J. Chappell, R. D’Arcy, P. Gonzalez, A. Knetsch, V. Libov, G. Loisch, A. Martinez de la Ossa, P. Niknejadi, K. Põder, L. Schaper, B. Schmidt, B. Sheeran, S. Wesch, J. Wood, and J. Osterhoff, Energy-spread preservation and high efficiency in a plasma-wakefield accelerator, Phys. Rev. Lett. 126, 014801 (2021).
  13. G. R. Plateau, C. G. R. Geddes, D. B. Thorn, M. Chen, C. Benedetti, E. Esarey, A. J. Gonsalves, N. H. Matlis, K. Nakamura, C. B. Schroeder, S. Shiraishi, T. Sokollik, J. van Tilborg, C. Toth, S. Trotsenko, T. S. Kim, M. Battaglia, T. Stöhlker, and W. P. Leemans, Low-emittance electron bunches from a laser-plasma accelerator measured using single-shot x-ray spectroscopy, Phys. Rev. Lett. 109, 064802 (2012).
  14. L. T. Ke, K. Feng, W. T. Wang, Z. Y. Qin, C. H. Yu, Y. Wu, Y. Chen, R. Qi, Z. J. Zhang, Y. Xu, X. J. Yang, Y. X. Leng, J. S. Liu, R. X. Li, and Z. Z. Xu, Near-GeV electron beams at a few per-mille level from a laser wakefield accelerator via density-tailored plasma, Phys. Rev. Lett. 126, 214801 (2021).
  15. Y. Wu, J. Hua, Z. Zhou, J. Zhang, S. Liu, B. Peng, Y. Fang, X. Ning, Z. Nie, F. Li, C. Zhang, C.-H. Pai, Y. Du, W. Lu, W. B. Mori, and C. Joshi, High-throughput injection–acceleration of electron bunches from a linear accelerator to a laser wakefield accelerator, Nat. Phys. 17, 801 (2021).
  16. T. Behnke, J. E. Brau, P. N. Burrows, J. Fuster, M. Peskin, M. Stanitzki, Y. Sugimoto, S. Yamada, and H. Yamamoto, The international linear collider technical design report - volume 4: Detectors, arXiv:1306.6329.
  17. I. Agapov et al., Future circular lepton collider FCC-ee: Overview and status, arXiv:2203.08310.
  18. T. C. S. Group, CEPC technical design report: Accelerator (v2), arXiv:2312.14363.
  19. J. Vieira and J. T. Mendonça, Nonlinear laser driven donut wakefields for positron and electron acceleration, Phys. Rev. Lett. 112, 215001 (2014).
  20. L.-L. Yu, C. B. Schroeder, F.-Y. Li, C. Benedetti, M. Chen, S.-M. Weng, Z.-M. Sheng, and E. Esarey, Control of focusing fields for positron acceleration in nonlinear plasma wakes using multiple laser modes, Phys. Plasmas 21, 120702 (2014).
  21. N. Jain, T. M. Antonsen, and J. P. Palastro, Positron acceleration by plasma wakefields driven by a hollow electron beam, Phys. Rev. Lett. 115, 195001 (2015).
  22. Z. Y. Xu, C. F. Xiao, H. Y. Lu, R. H. Hu, J. Q. Yu, Z. Gong, Y. R. Shou, J. X. Liu, C. Z. Xie, S. Y. Chen, H. G. Lu, T. Q. Xu, R. X. Li, N. Hafz, S. Li, Z. Najmudin, P. P. Rajeev, D. Neely, and X. Q. Yan, New injection and acceleration scheme of positrons in the laser-plasma bubble regime, Phys. Rev. Accel. Beams 23, 091301 (2020).
  23. W.-Y. Liu, X.-L. Zhu, M. Chen, S.-M. Weng, F. He, Z.-M. Sheng, and J. Zhang, Tail-wave-assisted positron acceleration in nonlinear laser plasma wakefields, Phys. Rev. Appl. 19, 044048 (2023).
  24. S. Diederichs, T. J. Mehrling, C. Benedetti, C. B. Schroeder, A. Knetsch, E. Esarey, and J. Osterhoff, Positron transport and acceleration in beam-driven plasma wakefield accelerators using plasma columns, Phys. Rev. Accel. Beams 22, 081301 (2019).
  25. S. Zhou, S. Ding, W. An, Q. Su, J. Hua, F. Li, W. B. Mori, C. Joshi, and W. Lu, Positron beam loading and acceleration in the blowout regime of a plasma wakefield accelerator, Research 8, 0878 (2025).
  26. T. C. Chiou, T. Katsouleas, C. Decker, W. B. Mori, J. S. Wurtele, G. Shvets, and J. J. Su, Laser wake-field acceleration and optical guiding in a hollow plasma channel, Phys. Plasmas 2, 310 (1995).
  27. T. C. Chiou and T. Katsouleas, High beam quality and efficiency in plasma-based accelerators, Phys. Rev. Lett. 81, 3411 (1998).
  28. C. B. Schroeder, D. H. Whittum, and J. S. Wurtele, Multimode analysis of the hollow plasma channel wakefield accelerator, Phys. Rev. Lett. 82, 1177 (1999).
  29. C. B. Schroeder, C. Benedetti, E. Esarey, and W. P. Leemans, Beam loading in a laser-plasma accelerator using a near-hollow plasma channel, Phys. Plasmas 20, 123115 (2013).
  30. S. Gessner et al., Demonstration of a positron beam-driven hollow channel plasma wakefield accelerator, Nat. Commun. 7, 11785 (2016).
  31. N. E. Andreev, S. S. Bychkov, V. V. Kotlyar, L. Y. Margolin, L. N. Pyatnitskii, and P. G. Serafimovich, Formation of high-power hollow Bessel light beams, Quantum Electron. 26, 126 (1996).
  32. J. Fan, E. Parra, I. Alexeev, K. Y. Kim, H. M. Milchberg, L. Y. Margolin, and L. N. Pyatnitskii, Tubular plasma generation with a high-power hollow Bessel beam, Phys. Rev. E 62, R7603(R) (2000).
  33. S. Liu, F. Li, Y. Du, B. Peng, Y. Fang, X. Ning, T. Zhang, J. Chen, Z. Song, H. Xiao, L. Zhou, B. Zhou, J. Hua, and W. Lu, Experimental demonstration of an emittance-preserving beam energy dechirper using a hollow channel plasma, Phys. Rev. Lett. 133, 175001 (2024).
  34. S. Zhou, J. Hua, W. An, W. B. Mori, C. Joshi, J. Gao, and W. Lu, High efficiency uniform wakefield acceleration of a positron beam using stable asymmetric mode in a hollow channel plasma, Phys. Rev. Lett. 127, 174801 (2021).
  35. C. Huang, V. K. Decyk, C. Ren, M. Zhou, W. Lu, W. B. Mori, J. H. Cooley, T. M. Antonsen Jr., and T. Katsouleas, Quickpic: A highly efficient particle-in-cell code for modeling wakefield acceleration in plasmas, J. Comput. Phys. 217, 658 (2006).
  36. W. An, V. K. Decyk, W. B. Mori, T. M. Antonsen Jr., An improved iteration loop for the three dimensional quasi-static particle-in-cell algorithm: Quickpic, J. Comput. Phys. 250, 165 (2013).
  37. R. Tang, W. An, J. Wang, W. Meng, H. Wang, J. Zhong, Y. Zhao, F. Li, Q. Su, L. Hildebrand, T. N. Dalichaouch, V. K. Decyk, and W. B. Mori, A particle-based field ionization algorithm in quasi–static PIC codes, Plasma Phys. Controlled Fusion 67, 075001 (2025).

Outline

Information

Phys. Rev. Accel. Beams 29, 103601– Published 7 October, 2026
  • Received 29 March 2026
  • Accepted 5 August 2026
Crossmark - Check for updates button
Creative Commons Logo

Published by the American Physical Society under the terms of the Creative Commons Attribution 4.0 International license. Further distribution of this work must maintain attribution to the author(s) and the published article’s title, journal citation, and DOI.
