Coupled amplitude-phase transport in heterogeneous optical media

Masaki Watabe1,2,*,†, Joe Sakamoto3,4,*, Hideaki Yoshimura5, Tomomi Nemoto3,4, and Kazunari Kaizu1,6

  • *These authors contributed equally to this work.
  • †Contact author: m-watabe@nibb.ac.jp

Phys. Rev. A 113, 053522 – Published 18 May, 2026

DOI: https://doi.org/10.1103/zjh7-3bdb

Abstract

The transport of intensity equation (TIE) enables deterministic phase retrieval in optical microscopy, yet its application to heterogeneous media exhibiting both refractive-index variations and attenuation remains an open problem. We derive a coupled TIE-TPE (transport of phase equation) framework from the paraxial wave equation with a complex optical potential, in which the refractive index field is decomposed into a spatially uniform mean field and a local fluctuation field through Reynolds decomposition. This formulation yields a nondivergent system of transport equations that simultaneously reconstructs refractive-index fluctuations and attenuation coefficients within the condition |Δn|<1, without requiring linearization or weak-absorption approximations. We establish explicit validity bounds that define the measurable parameter space for a given experimental configuration, emerging from both photon counting statistics and the diffraction limit. Experimental validation using microlens arrays and HeLa cells demonstrates robust recovery of optical properties, including in the transparent-limit regime where attenuation signals approach detection thresholds. We further verify that the attenuation asymmetry parameter remains consistent with zero across three orders of magnitude in optical depth, indicating preservation of optical reciprocity in structurally heterogeneous biological media.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (20)

  1. M. R. Teague, Deterministic phase retrieval: A Green's function solution, J. Opt. Soc. Am. 73, 1434 (1983).
  2. M. R. Teague, Irradiance moments: Their propagation and use for unique retrieval of phase, J. Opt. Soc. Am. 72, 1199 (1982).
  3. N. C. Ruppel and M. A. Model, A guide to transport-of-intensity equation (TIE) imaging for biologists, Prog. Biophys. Mol. Biol. 198, 1 (2025).
  4. N. Yoneda, J. Sakamoto, T. Tomoi, T. Nemoto, Y. Tamada, and O. Matoba, Transport-of-intensity phase imaging using commercially available confocal microscope, J. Biomed. Opt. 29, 116002 (2024).
  5. C. Zuo, J. Li, J. Sun, Y. Fan, J. Zhang, L. Lu, R. Zhang, B. Wang, L. Huang, and Q. Chen, Transport of intensity equation: A tutorial, Opt. Lasers Eng. 135, 106187 (2020).
  6. J. Li, N. Zhou, J. Sun, S. Zhou, Z. Bai, L. Lu, Q. Chen, and C. Zuo, Transport of intensity diffraction tomography with non-interferometric synthetic aperture for three-dimensional label-free microscopy, Light: Sci. Appl. 11, 154 (2022).
  7. M. H. Jenkins and T. K. Gaylord, Three-dimensional quantitative phase imaging via tomographic deconvolution phase microscopy, Appl. Opt. 54, 9213 (2015).
  8. Z. Bai, Q. Chen, H. Ullah, L. Lu, N. Zhou, S. Zhou, J. Li, and C. Zuo, Absorption and phase decoupling in transport of intensity diffraction tomography, Opt. Lasers Eng. 156, 107082 (2022).
  9. E. Wolf, Three-dimensional structure determination of semi-transparent objects from holographic data, Opt. Commun. 1, 153 (1969).
  10. R. J. Potton, Reciprocity in optics, Rep. Prog. Phys. 67, 717 (2004).
  11. M. Watabe, Y. Hirano, A. Iwane, O. Matoba, and K. Takahashi, Optical dispersions through intracellular inhomogeneities, Phys. Rev. Res. 5, L022043 (2023).
  12. S. Mazumder, Numerical Methods for Partial Differential Equations: Finite Difference and Finite Volume Methods, 1st ed. (Academic Press, New York, 2016).
  13. B. Xue and S. Zheng, Phase retrieval using the transport of intensity equation solved by the FMG-CG method, Optik (Stuttgart, Ger.) 122, 2101 (2011).
  14. S. V. Pinhasi, R. Alimi, L. Perelmutter, and S. Eliezer, Topography retrieval using different solutions of the transport intensity equation, J. Opt. Soc. Am. A 27, 2285 (2010).
  15. W. H. Press, S. A. Teukolsky, W. T. Vetterling, and B. P. Flannery, Numerical Recipes in C: The Art of Scientific Computing, 2nd ed. (Cambridge University Press, Cambridge, UK, 1992).
  16. MLA300-14AR-M-ϕ1″ mounted lens array–Thorlabs, https://www.thorlabs.co.jp/thorproduct.cfm?partnumber=MLA300-14AR-M, accessed: 2025-05-01.
  17. Data is available at Zenodo, https://doi.org/10.5281/zenodo.15589385.
  18. M. Watabe, Physical constraints to phase retrieval using the transport of intensity equation in fluorescence microscopy imaging, presented at the 1st Conference for Sensing and Imaging Through Scattering and Fluctuating Field in Biology, Telecommunication and Astronomy (SI-Thru2022), April 19–22, 2022 at Pacifico Yokohama, Japan (Optics & Photonics International Council, Tokyo, Japan, 2022).
  19. T. Yamada, H. Yoshimura, R. Shimada, M. Hattori, M. Eguchi, T. K. Fujiwara, A. Kusumi, and T. Ozawa, Spatiotemporal analysis with a genetically encoded fluorescent RNA probe reveals TERRA function around telomeres, Sci. Rep. 6, 38910 (2016).
  20. Xenon arc light sources–Thorlabs, https://www.thorlabs.com/newgrouppage9.cfm?objectgroup_ID=13016, accessed: 2025-04-10.
