K-shell ionization and characteristic x-ray radiation by high-energy electrons and positrons in oriented silicon crystals

S. V. Trofymenko* and I. V. Kyryllin†

  • *Contact author: trofymenko@kipt.kharkov.ua
  • †Contact author: i.kyryllin@gmail.com
PDF

Phys. Rev. A 113, 032808 – Published 5 March, 2026

DOI: https://doi.org/10.1103/yfyn-lvbf

Abstract

K-shell ionization and characteristic x-ray radiation (CXR) by high-energy electrons and positrons in oriented silicon crystals are studied using computer simulation. A method for this simulation has been developed and is described in detail. The evolution of the angular distribution of CXR from the upstream surface of the crystal with changes in the angle between the incident particle momentum and the crystal 〈100〉 axis or (100) plane, as well as with changes in particle energy over a wide range (1–1000 GeV), is investigated. It is shown that in most cases this evolution is nonmonotonic. The physical mechanisms underlying this behavior are discussed. In particular, the impact of the dechanneling process on CXR produced by electrons is analyzed.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (63)

  1. A. I. Akhiezer and N. F. Shul'ga, High Energy Electrodynamics in Matter (Gordon and Breach, Amsterdam, 1996).
  2. P. Sigmund, Particle Penetration and Radiation Effects (Springer, Berlin, 2006).
  3. Particle Physics Reference Library, Volume 2: Detectors for Particles and Radiation, edited by C. W. Fabjan and H. Schopper (Springer, Cham, 2020).
  4. V. L. Ginzburg and V. N. Tsytovich, Transition Radiation and Transition Scattering (Hilger, Bristol, 1984).
  5. J. F. Bak, F. E. Meyer, J. B. B. Petersen, E. Uggerhøj, K. Østergaard, S. P. Møller, A. H. Sørensen, and P. Siffert, Phys. Rev. Lett. 51, 1163 (1983).
  6. S. V. Trofymenko, Phys. Rev. A 102, 062804 (2020).
  7. R. O. Müller, Spectrochemical Analysis by X-Ray Fluorescence (Springer, New York, 1972).
  8. I. Chaikovska, R. Chehab, X. Artru, and A. V. Shchagin, Nucl. Instrum. Methods Phys. Res. Sect. B 402, 75 (2017).
  9. R. M. Nazhmudinov, A. S. Kubankin, P. V. Karataev, I. A. Kishin, A. V. Vukolov, A. P. Potylitsyn, P. N. Zhukova, and V. A. Nasonova, J. Instrum. 13, P12012 (2018).
  10. L. M. Middleman, R. L. Ford, and R. Hofstadter, Phys. Rev. A 2, 1429 (1970).
  11. G. R. Dangerfield and B. M. Spicer, J. Phys. B 8, 1744 (1975).
  12. K. Ishii, M. Kamiya, K. Sera, S. Morita, H. Tawara, M. Oyamada, and T. C. Chu, Phys. Rev. A 15, 906 (1977).
  13. D. H. H. Hoffmann, C. Brendel, H. Genz, W. Löw, S. Müller, and A. Richter, Z. Phys. A 293, 187 (1979).
  14. M. Kamiya, A. Kuwako, K. Ishii, S. Morita, and M. Oyamada, Phys. Rev. A 22, 413 (1980).
  15. H. Genz, C. Brendel, P. Eschwey, U. Kuhn, W. Löw, A. Richter, P. Seserko, and R. Sauerwein, Z. Phys. A 305, 9 (1982).
  16. J. F. Bak, J. B. B. Petersen, E. Uggerhøj, K. Østergaard, S. P. Møller, and A. H. Sørensen, Phys. Scr. 33, 147 (1986).
  17. W. E. Meyerhof, D. G. Jensen, D. M. Kawall, S. E. Kuhn, D. W. Spooner, Z. E. Meziani, and D. N. Faust, Phys. Rev. Lett. 68, 2293 (1992).
  18. D. W. Spooner, W. E. Meyerhof, J. J. Kuffner, E. C. Montenegro, K. Ishii, S. E. Kuhn, D. M. Kawall, D. G. Jensen, and Z. E. Meziani, Z. Phys. D 29, 265 (1994).
  19. A. V. Shchagin, V. I. Pristupa, and N. A. Khizhnyak, Nucl. Instrum. Methods Phys. Res. Sect. B 84, 9 (1994).
  20. R. M. Nazhmudinov, A. V. Shchagin, S. V. Trofymenko, I. A. Kishin, et al., J. Phys. B 54, 045201 (2021).
  21. H. Kolbenstvedt, J. Appl. Phys. 38, 4785 (1967).
  22. H. Kolbenstvedt, J. Appl. Phys. 46, 2771 (1975).
  23. F. Komarov, Radiat. Eff. 46, 39 (1980).
  24. P. A. Amundsen and K. Aashamar, J. Phys. B 14, 4047 (1981).
  25. A. H. Sørensen and E. Uggerhøj, Comments At. Mol. Phys. 17, 285 (1986).
  26. V. K. Ermilova and V. A. Chechin, Sov. Phys. JETP Lett. 45, 676 (1987).
  27. A. H. Sørensen, Phys. Rev. A 36, 3125 (1987).
  28. V. A. Chechin and V. K. Ermilova, Z. Phys. D 13, 33 (1989).
  29. E. Fermi, Phys. Rev. 57, 485 (1940).
  30. R. M. Sternheimer, M. J. Berger, and S. M. Seltzer, At. Data Nucl. Data Tables 30, 261 (1984).
  31. J. Lindhard, Dan. Vid. Selsk. Mat. Fys. Medd. 34, 14 (1965).
  32. V. N. Baier, V. M. Katkov, and V. V. Strakhovenko, Electromagnetic Processes at High Energies in Oriented Single Crystals (World Scientific, Singapore, 1998).
  33. U. I. Uggerhøj, Rev. Mod. Phys. 77, 1131 (2005).
  34. O. Fich, J. A. Golovchenko, K. O. Nielsen, E. Uggerhøj, C. Vraast-Thomsen, G. Charpak, S. Majewski, F. Sauli, and J. P. Ponpon, Phys. Rev. Lett. 36, 1245 (1976).
  35. H. Esbensen, O. Fich, J. A. Golovchenko, K. O. Nielsen, E. Uggerhøj, C. Vraast-Thomsen, G. Charpak, S. Majewski, F. Sauli, and J. P. Ponpon, Nucl. Phys. B 127, 281 (1977).
  36. H. Esbensen, O. Fich, J. A. Golovchenko, et al., Phys. Rev. B 18, 1039 (1978).
  37. D. I. Adejshvili, G. L. Bochek, V. I. Vit'ko, et al., Radiat. Eff. 71, 185 (1983).
  38. S. Pape Møller, V. Biryukov, S. Datz, P. Grafstrom, H. Knudsen, H. F. Krause, C. Scheidenberger, U. I. Uggerhoj, and C. R. Vane, Phys. Rev. A 64, 032902 (2001).
  39. L. D. Landau, J. Phys. USSR 8, 201 (1944).
  40. S. V. Trofymenko and I. V. Kyryllin, Eur. Phys. J. C 84, 1207 (2024).
  41. S. V. Trofymenko and I. V. Kyryllin, Eur. Phys. J. C 85, 682 (2025).
  42. W. Brandt, J. M. Khan, D. L. Potter, R. D. Worley, and H. P. Smith, Jr., Phys. Rev. Lett. 14, 42 (1965).
  43. J. M. Khan, D. L. Potter, R. D. Worley, and H. P. Smith, Jr., Phys. Rev. 148, 413 (1966).
  44. A. I. Kosse, F. G. Neshov, A. A. Pusanov, A. R. Urmanov, A. F. Burenkov, and F. F. Komarov, Radiat. Eff. 77, 205 (1983).
  45. C. R. Hall, Proc. R. Soc. A 295, 140 (1966).
  46. B. D. Grachev, A. P. Komar, Y. S. Korobochko, and V. I. Mineev, JETP Lett. 4, 163 (1966).
  47. J. F. Bak, G. Melchart, E. Uggerhøj, et al., Phys. Rev. A 25, 1334 (1982).
  48. A. N. Aleinik, Y. N. Adishev, S. A. Vorobiev, et al., Pis'ma Zh. Tekh. Fiz. 13, 1367 (1987).
  49. M. Andreyashkin, M. Inoue, H. Nakagawa, et al., Nucl. Instrum. Methods Phys. Res. Sect. B 173, 142 (2001).
  50. A. Sytov, G. Kube, L. Bandiera, et al., Eur. Phys. J. C 82, 197 (2022).
  51. I. V. Kyryllin and N. F. Shul'ga, Eur. Phys. J. C 83, 34 (2023).
  52. S. M. Darbinian and K. A. Ispirian, Radiat. Eff. 62, 207 (1982).
  53. L. D. Landau and E. M. Lifshitz, Quantum Mechanics: Non-Relativistic Theory (Butterworth-Heinemann, Oxford, 1981).
  54. S. V. Trofymenko, Phys. Rev. A 98, 023813 (2018).
  55. G. M. Garibyan, Sov. Phys. JETP 11, 1306 (1960).
  56. X-ray attenuation length, https://henke.lbl.gov/optical_ constants/atten2.html (2010).
  57. J. F. Bak, A. Burenkov, J. B. B. Petersen, E. Uggerhøj, S. P. Møller, and P. Siffert, Nucl. Phys. B 288, 681 (1987).
  58. P. A. Doyle and P. S. Turner, Acta Crystallogr. A 24, 390 (1968).
  59. I. V. Kyryllin and N. F. Shul'ga, J. Instrum. 13, C02020 (2018).
  60. I. S. Gradshteyn and I. M. Ryzhik, Table of Integrals, Series, and Products, 7th ed. (Academic, London, 2007).
  61. N. F. Shul'ga, I. V. Kirillin, and V. I. Truten', J. Synch. Investig. 7, 398 (2013).
  62. H. Backe, P. Kunz, W. Lauth, and A. Rueda, Nucl. Instrum. Methods Phys. Res. Sect. B 266, 3835 (2008).
  63. M. Soldani, P. Monti-Guarnieri, A. Selmi, et al., Eur. Phys. J. C 85, 1239 (2025).

Outline

Information

Phys. Rev. A 113, 032808– Published 5 March, 2026
  • Received 18 November 2025
  • Accepted 10 February 2026
