QED vacuum polarization in the Coulomb field of a nucleus: A method of high-order calculation

Sergey Volkov*

  • *Contact author: sergey.volkov.1811@gmail.com, volkoff_sergey@mail.ru; svolkov@mpi-hd.mpg.de
PDF

Phys. Rev. A 113, 042823 – Published 28 April, 2026

DOI: https://doi.org/10.1103/nstc-qqwm

Abstract

A calculation of the quantum electrodynamics (QED) vacuum polarization potential in the Coulomb field of a pointlike nucleus was presented in an earlier publication by the author and his collaborators. Corrections up to order α2(Zα)7 were evaluated, where Z is the nuclear charge number and Zα is treated as an independent variable. These corrections correspond to two-loop Feynman graphs with proper propagators of fermions in the external field. The calculation employed a reduction to free QED, leading to free QED Feynman graphs with up to eight independent loops. The method of calculation is described here in detail.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (48)

  1. P. Indelicato, QED tests with highly charged ions, J. Phys. B: At., Mol. Opt. Phys. 52, 232001 (2019).
  2. M. I. Eides, H. Grotch, and V. A. Shelyuto, Theory of Light Hydrogenic Bound States (Springer, Berlin, 2007).
  3. V. A. Yerokhin and V. M. Shabaev, Lamb shift of n = 1 and n = 2 states of hydrogen-like atoms, 1 ≤Z≤110, J. Phys. Chem. Ref. Data 44, 033103 (2015).
  4. J. Blomqvist, Vacuum polarization in exotic atoms, Nucl. Phys. B 48, 95 (1972).
  5. E. A. Uehling, Polarization effects in the positron theory, Phys. Rev. 48, 55 (1935).
  6. E. H. Wichmann and N. M. Kroll, Vacuum polarization in a strong coulomb field, Phys. Rev. 101, 843 (1956).
  7. G. Soff and P. Mohr, Vacuum polarization in a strong external field, Phys. Rev. A 38, 5066 (1988).
  8. N. L. Manakov, A. A. Nekipelov, and A. G. Fainshtein, Vacuum polarization by a strong coulomb field and its contribution to the spectra of multiply-charged ions, Zh. Eksp. Teor. Fiz. 95, 1167 (1989) [Sov. Phys. JETP 68, 673 (1989)].
  9. A. G. Fainshtein, N. L. Manakov, and A. A. Nekipelov, Vacuum polarization by a Coulomb field. Analytical approximation of the polarization potential, J. Phys. B: At. Mol. Opt. Phys. 24, 559 (1991).
  10. N. L. Manakov and A. A. Nekipelov, Proc. Voronezh State University 2, 53 (2012) (in Russian).
  11. G. Källen and A. Sabry, Fourth order vacuum polarization, Dan. Mat. Fys. Medd. 29, 555 (1955).
  12. L. W. Fullerton and J. G. A. Rinker, Accurate and efficient methods for the evaluation of vacuum-polarization potentials of order Zα and Zα2, Phys. Rev. A 13, 1283 (1976).
  13. P. A. Krachkov and R. N. Lee, O(mα2(Zα)6) contribution to Lamb shift from radiative corrections to the Wichmann-Kroll potential, J. High Energy Phys. 12 (2023) 147.
  14. S. Volkov, V. A. Yerokhin, Z. Harman and C. H. Keitel, Two-loop vacuum polarization in a Coulomb field, Phys. Rev. A 112, 062814 (2025) .
  15. V. A. Yerokhin, P. Indelicato, and V. M. Shabaev, Evaluation of the two-loop self-energy correction to the ground state energy of H-like ions to all orders in Zα, Eur. Phys. J. D 25, 203 (2003).
  16. S. Mallampalli and J. Sapirstein, Fourth-order vacuum-polarization contribution to the Lamb shift, Phys. Rev. A 54, 2714 (1996).
  17. I. Goidenko, L. Labzowsky, A. Nefioodv, G. Plunien, and G. Soff, Second-order electron self-energy in H-like ions, Phys. Rev. Lett. 83, 2312 (1999).
  18. L. N. Labzowsky and A. O. Mitrushenkov, Renormalization of the second-order electron self-energy for a tightly bound atomic electron: A detailed derivation, Phys. Rev. A 53, 3029 (1996).
  19. B. Sikora, V. A. Yerokhin, C. H. Keitel, and Z. Harman, Improved bound-electron g-factor theory through complete two-loop QED calculations, Phys. Rev. Lett. 134, 123001 (2025).
  20. S. Volkov, Calculation of the total 10th order QED contribution to the electron magnetic moment, Phys. Rev. D 110, 036001 (2024).
  21. M. J. Levine and J. Wright, Anomalous magnetic moment of the electron, Phys. Rev. D 8, 3171 (1973).
  22. R. Carroll and Y. Yao, α3 contributions to the anomalous magnetic moment of an electron in the mass-operator formalism, Phys. Lett. B 48, 125 (1974).
  23. P. Cvitanović and T. Kinoshita, Sixth order magnetic moment of the electron, Phys. Rev. D 10, 4007 (1974).
  24. T. Kinoshita and W. B. Lindquist, Eighth-order anomalous magnetic moment of the electron, Phys. Rev. Lett. 47, 1573 (1981).
  25. T. Aoyama, M. Hayakawa, T. Kinoshita, and M. Nio, Tenth-order QED contribution to the electron g−2 and an improved value of the fine structure constant, Phys. Rev. Lett. 109, 111807 (2012).
  26. T. Aoyama, M. Hayakawa, A. Hirayama, and M. Nio, Verification of the tenth-order QED contribution to the anomalous magnetic moment of the electron from diagrams without fermion loops, Phys. Rev. D 111, L031902 (2025).
  27. L. T. Adzhemyan and M. V. Kompaniets, Five-loop numerical evaluation of critical exponents of the φ4 theory, in J. Phys.: Conf. Ser. 523, 0120492014).
  28. N. N. Bogoliubov and O. S. Parasiuk, On the multiplication of the causal function in the quantum theory of fields, Acta Math. 97, 227 (1957) [in German].
  29. K. Hepp, Proof of the Bogolyubov-Parasiuk theorem on renormalization, Commun. Math. Phys. 2, 301 (1966).
  30. W. Zimmermann, Convergence of Bogoliubov's method of renormalization in momentum space, Commun. Math. Phys. 15, 208 (1969).
  31. S. Zschocke, G. Plunien, and G. Soff, Renormalization of the two-photon vacuum polarization and the self energy vacuum polarization for a tightly bound electron, Eur. Phys. J. D 19, 147 (2002).
  32. M. E. Peskin and D. V. Schroeder, An Introduction to Quantum Field Theory (Perseus Books, New York, 1995).
  33. O. I. Zavialov and B. M. Stepanov, Asymptotics of divergent Feynman diagrams, Yad. Fys. 1, 922 (1965) [Sov. J. Nucl. Phys. 1, 658 (1965)].
  34. P. Cvitanović and T. Kinoshita, New approach to the separation of ultraviolet and infrared divergences of Feynman - parametric integrals, Phys. Rev. D 10, 3991 (1974).
  35. S. Volkov, Subtractive procedure for calculating the anomalous electron magnetic moment in QED and its application for numerical calculation at the three-loop level, Zh. Eksp. Teor. Fiz. 149, 1164 (2016) [JETP 122, 1008 (2016)].
  36. S. Volkov, Calculation of lepton magnetic moments in quantum electrodynamics: A justification of the flexible divergence elimination method, Phys. Rev. D 109, 036012 (2024).
  37. J. Collins, Renormalization (Cambridge University Press, Cambridge, 1984).
  38. N. N. Bogoliubov and D. V. Shirkov, Introduction to the Theory of Quantized Fields (Wiley, New York, 1980).
  39. J. D. Bjorken and S. D. Drell, Relativistic Quantum Fields (McGraw-Hill, New York, 1965).
  40. O. I. Zavyalov, Renormalized Quantum Field Theory (Kluwer, Dordrecht, 1990).
  41. V. A. Smirnov, Renormalization and Asymptotic Expansions (Birkhäuser, Basel, 1991).
  42. E. Speer, Analytic Renormalization, J. Math. Phys. 9, 1404 (1968).
  43. S. Volkov, New method of computing the contributions of graphs without lepton loops to the electron anomalous magnetic moment in QED, Phys. Rev. D 96, 096018 (2017).
  44. M. Borinsky, Tropical Monte Carlo quadrature for Feynman integrals, Ann. Inst. H. Poincaré D 10, 635 (2023).
  45. M. Borinsky, H. J. Munch, and F. Tellander, Tropical Feynman integration in the Minkowski regime, Comput. Phys. Commun. 292, 108874 (2023).
  46. S. Volkov, Infrared and ultraviolet power counting on the mass shell in quantum electrodynamics, Nucl. Phys. B 961, 115232 (2020).
  47. S. Volkov, Numerical calculation of high-order QED contributions to the electron anomalous magnetic moment, Phys. Rev. D 98, 076018 (2018).
  48. S. Volkov, Calculating the five-loop QED contribution to the electron anomalous magnetic moment: Graphs without lepton loops, Phys. Rev. D 100, 096004 (2019).

Outline

Information

Phys. Rev. A 113, 042823– Published 28 April, 2026
  • Received 4 November 2025
  • Accepted 27 March 2026
