Open Access

$J$ = 0 metastable state of ${Th}^{2 +}$ for a hyperfine-free nuclear clock

S. Sagar Maurya , V. Lal , J. Tiedau , M. V. Okhapkin , and E. Peik ^*

Physikalisch-Technische Bundesanstalt (PTB), Bundesallee 100, 38116 Braunschweig, Germany

^*Contact author: ekkehard.peik@ptb.de

Phys. Rev. A 114, 032819 – Published 17 September, 2026

DOI: https://doi.org/10.1103/c98g-6f84

Abstract

We present measurements on a metastable state in ${Th}^{2 +}$ with the electronic configuration $6 d^{2} {}^{3}P_{0} (5090 {cm}^{- 1})$ . This is motivated by the prospect of using the state in laser excitation of the low-energy ${}^{229}{Th}$ nuclear resonance independent from the leading hyperfine interactions. The $6 d^{2} {}^{3}P_{0}$ state has no dipole-allowed radiative decay channel and is connected to the second ground state $6 d^{2}^{3} F_{2} (63 {cm}^{- 1})$ through an electric quadrupole transition only. We populate the state by laser excitation at 484 nm via a higher excited level and detect its population in laser-induced fluorescence. The isotope shift of the $J = 0$ level between ${}^{232}{Th}^{2 +}$ and ${}^{229}{Th}^{2 +}$ is determined as a measure of the interaction of electronic and nuclear charge distributions. The lifetime of the level in our ion trap with buffer gas is limited by collisional mixing with the nearby state $5 f 6 d {}^{3}G_{3} (5060 {cm}^{- 1})$ . In ultrahigh vacuum, it could serve as a hyperfine-free nuclear clock that is largely immune to field-induced frequency shifts via the electron shell.

Physics Subject Headings (PhySH)

Article Text

References (53)

E. Peik and C. Tamm, Nuclear laser spectroscopy of the 3.5 eV transition in Th-229, Europhys. Lett. 61, 181 (2003).
C. J. Campbell, A. G. Radnaev, A. Kuzmich, V. A. Dzuba, V. V. Flambaum, and A. Derevianko, Single-ion nuclear clock for metrology at the 19th decimal place, Phys. Rev. Lett. 108, 120802 (2012).
J. Tiedau, M. V. Okhapkin, K. Zhang, J. Thielking, G. Zitzer, E. Peik, F. Schaden, T. Pronebner, I. Morawetz, L. T. De Col, F. Schneider, A. Leitner, M. Pressler, G. A. Kazakov, K. Beeks, T. Sikorsky, and T. Schumm, Laser excitation of the Th-229 nucleus, Phys. Rev. Lett. 132, 182501 (2024).
R. Elwell, C. Schneider, J. Jeet, J. E. S. Terhune, H. W. T. Morgan, A. N. Alexandrova, H. B. Tran Tan, A. Derevianko, and E. R. Hudson, Laser excitation of the ${}^{229}{Th}$ nuclear isomeric transition in a solid-state host, Phys. Rev. Lett. 133, 013201 (2024).
C. Zhang, T. Ooi, J. S. Higgins, J. F. Doyle, L. von der Wense, K. Beeks, A. Leitner, G. A. Kazakov, P. Li, P. G. Thirolf, T. Schumm, and J. Ye, Frequency ratio of the ${}^{229 m}{Th}$ nuclear isomeric transition and the ${}^{87}{Sr}$ atomic clock, Nature (London) 633, 63 (2024).
T. Ooi, J. F. Doyle, C. Zhang, J. S. Higgins, J. Ye, K. Beeks, T. Sikorsky, and T. Schumm, Frequency reproducibility of solid-state thorium-229 nuclear clocks, Nature (London) 650, 72 (2026).
K. Beloy, Trap-induced ac Zeeman shift of the thorium-229 nuclear clock frequency, Phys. Rev. Lett. 130, 103201 (2023).
A. Chakraborty and B. K. Sahoo, Comprehensive assessment of ${Th}^{3 +}$ properties for nuclear clock and fundamental physics applications, Phys. Rev. A 113, L020801 (2026).
S. L. Redman, G. Nave, and C. J. Sansonetti, The spectrum of thorium from 250 nm to 5500 nm: Ritz wavelengths and optimized energy levels, Astrophys. J. Suppl. Ser. 211, 4 (2014).
E. Biémont, P. Palmeri, P. Quinet, Z. G. Zhang, and S. Svanberg, Doubly ionized thorium: Laser lifetime measurements and transition probability determination of interest in cosmochronology, Astrophys. J. 567, 1276 (2002).
M. S. Safronova, U. I. Safronova, and C. W. Clark, Relativistic all-order calculations of Th, ${Th}^{+}$ , and $Th^{2} +$ atomic properties, Phys. Rev. A 90, 032512 (2014).
J.-F. Wyart and V. Kaufman, Extended analysis of doubly ionized thorium (Th III), Phys. Scr. 24, 941 (1981).
C. J. Campbell, A. G. Radnaev, and A. Kuzmich, Wigner crystals of ${}^{229}{Th}$ for optical excitation of the nuclear isomer, Phys. Rev. Lett. 106, 223001 (2011).
C. J. Campbell, A. V. Steele, L. R. Churchill, M. V. DePalatis, D. E. Naylor, D. N. Matsukevich, A. Kuzmich, and M. S. Chapman, Multiply charged thorium crystals for nuclear laser spectroscopy, Phys. Rev. Lett. 102, 233004 (2009).
A. G. Radnaev, C. J. Campbell, and A. Kuzmich, Observation of the 717-nm electric quadrupole transition in triply charged thorium, Phys. Rev. A 86, 060501(R) (2012).
U. I. Safronova, W. R. Johnson, and M. S. Safronova, Excitation energies, polarizabilities, multipole transition rates, and lifetimes in Th iv, Phys. Rev. A 74, 042511 (2006).
M. S. Safronova, U. I. Safronova, and M. G. Kozlov, Atomic properties of actinide ions with particle-hole configurations, Phys. Rev. A 97, 012511 (2018).
V. V. Flambaum, V. A. Dzuba, and E. Peik, Nuclear clock based on the Th v ion, Phys. Rev. A 112, 023103 (2025).
G. Zitzer, J. Tiedau, C. E. Düllmann, M. V. Okhapkin, and E. Peik, Laser spectroscopy on the hyperfine structure and isotope shift of sympathetically cooled ${}^{229}{Th}^{3 +}$ ions, Phys. Rev. A 111, L050802 (2025).
M. V. Okhapkin, D. M. Meier, E. Peik, M. S. Safronova, M. G. Kozlov, and S. G. Porsev, Observation of an unexpected negative isotope shift in ${}^{229}{Th}^{+}$ and its theoretical explanation, Phys. Rev. A 92, 020503(R) (2015).
J. Thielking, M. V. Okhapkin, P. Głowacki, D. M. Meier, L. von der Wense, B. Seiferle, C. E. Düllmann, P. G. Thirolf, and E. Peik, Laser spectroscopic characterization of the nuclear-clock isomer ${}^{229 m}{Th}$ , Nature (London) 556, 321 (2018).
A. Yamaguchi, Y. Shigekawa, H. Haba, H. Kikunaga, K. Shirasaki, M. Wada, and H. Katori, Laser spectroscopy of triply charged ${}^{229}{Th}$ isomer for a nuclear clock, Nature (London) 629, 62 (2024).
L. v. d. Wense, B. Seiferle, M. Laatiaoui, and P. G. Thirolf, Determination of the extraction efficiency for ${}^{233}U$ source $α$ -recoil ions from the MLL buffer-gas stopping cell, Eur. Phys. J. A 51, 29 (2015).
K. Beeks, T. Sikorsky, T. Schumm, J. Thielking, M. V. Okhapkin, and E. Peik, The thorium-229 low-energy isomer and the nuclear clock, Nat. Rev. Phys. 3, 238 (2021).
V. A. Dzuba and V. V. Flambaum, Using the Th iii ion for a nuclear clock and searches for new physics, Phys. Rev. A 111, 053109 (2025).
V. I. Yudin, A. V. Taichenachev, O. N. Prudnikov, M. Y. Basalaev, A. N. Goncharov, S. V. Chepurov, and V. G. Pal'chikov, Optical clock based on two-photon spectroscopy of the nuclear transition in a ${}^{229}{Th}$ ion in a monochromatic field, JETP Lett. 121, 345 (2025).
O. A. Herrera-Sancho, M. V. Okhapkin, K. Zimmermann, C. Tamm, E. Peik, A. V. Taichenachev, V. I. Yudin, and P. Głowacki, Two-photon laser excitation of trapped ${}^{232}{Th}^{+}$ ions via the 402-nm resonance line, Phys. Rev. A 85, 033402 (2012).
O. A. Herrera-Sancho, N. Nemitz, M. V. Okhapkin, and E. Peik, Energy levels of ${Th}^{+}$ between 7.3 and 8.3 eV, Phys. Rev. A 88, 012512 (2013).
P. Staanum, I. S. Jensen, R. G. Martinussen, D. Voigt, and M. Drewsen, Lifetime measurement of the metastable $3 d^{2} D_{5 / 2}$ state in the ${}^{40}{Ca}^{+}$ ion using the shelving technique on a few-ion string, Phys. Rev. A 69, 032503 (2004).
M. Fan, C. A. Holliman, A. Contractor, C. Zhang, S. F. Gebretsadkan, and A. M. Jayich, Measurement of the ${Ra}^{+} 7 p^{2} P_{3 / 2}$ state lifetime, Phys. Rev. A 105, 042801 (2022).
B. A. Palmer and R. J. Engleman, Atlas of the thorium spectrum, Techical Report No. LA-9615, Los Alamos National Laboratory (LANL), Los Alamos, NM, 1983.
J. E. Bjorkholm and P. F. Liao, Line shape and strength of two-photon absorption in an atomic vapor with a resonant or nearly resonant intermediate state, Phys. Rev. A 14, 751 (1976).
E. C. Cook, A. D. Vira, and W. D. Williams, Resonant two-photon spectroscopy of the $2 s 3 d^{1} D_{2}$ level of neutral ${}^{9}{Be}$ , Phys. Rev. A 101, 042503 (2020).
M. S. Safronova, S. G. Porsev, M. G. Kozlov, J. Thielking, M. V. Okhapkin, P. Głowacki, D. M. Meier, and E. Peik, Nuclear charge radii of ${}^{229}{Th}$ from isotope and isomer shifts, Phys. Rev. Lett. 121, 213001 (2018).
R. A. Müller, A. V. Maiorova, S. Fritzsche, A. V. Volotka, R. Beerwerth, P. Glowacki, J. Thielking, D.-M. Meier, M. Okhapkin, E. Peik, and A. Surzhykov, Hyperfine interaction with the ${}^{229}{Th}$ nucleus and its low-lying isomeric state, Phys. Rev. A 98, 020503(R) (2018).
D. P. Moehs and D. A. Church, Magnetic dipole transition rates from measured lifetimes of levels of Be-like and B-like argon ions, Phys. Rev. A 58, 1111 (1998).
E. Träbert, Atomic lifetime measurements with ion traps of many sizes, Phys. Scr. 61, 257 (2000).
E. Träbert, Limits to the precision of atomic lifetime measurements, Atoms 12, 73 (2024).
M. A. Gearba, J. H. Wells, P. H. Rich, J. M. Wesemann, L. A. Zimmerman, B. M. Patterson, R. J. Knize, and J. F. Sell, Collisional excitation transfer and quenching in $Rb (5 P)$ -methane mixtures, Phys. Rev. A 99, 022706 (2019).
M. Endo, H. Nagaoka, and F. Wani, Collisional mixing and quenching cross sections of Cs $6^{2} P$ levels with methane, ethane, and propane, Opt. Express 29, 42887 (2021).
G. Zitzer, J. Tiedau, M. V. Okhapkin, K. Zhang, C. Mokry, J. Runke, C. E. Düllmann, and E. Peik, Sympathetic cooling of trapped ${Th}^{3 +}$ alpha-recoil ions for laser spectroscopy, Phys. Rev. A 109, 033116 (2024).
D. Moritz, K. Scharl, M. Wiesinger, G. Holthoff, T. Teschler, M. I. Hussain, J. R. Crespo López-Urrutia, T. Dickel, S. Ding, C. E. Düllmann, E. R. Hudson, S. Kraemer, L. Löbell, C. Mokry, J. Runke, B. Seiferle, L. von der Wense, F. Zacherl, and P. G. Thirolf, A cryogenic Paul trap for probing the nuclear isomeric excited state ${}^{229 m}{Th}^{3 +}$ , Eur. Phys. J. D 79, 127 (2025).
J. Spahn, H. Bodnar, K. König, and W. Nörtershäuser, Demonstration of a Raman velocity filter in collinear laser spectroscopy: Towards applications for sub-ppm high-voltage measurements, New J. Phys. 28, 053202 (2026).
S. P. Carman, J. Rudolph, B. E. Garber, M. J. Van de Graaff, H. Swan, Y. Jiang, M. Nantel, M. Abe, R. L. Barcklay, and J. M. Hogan, Collinear three-photon excitation of a strongly forbidden optical clock transition, Phys. Rev. X 15, 031051 (2025).
H. Levine, D. Bluvstein, A. Keesling, T. T. Wang, S. Ebadi, G. Semeghini, A. Omran, M. Greiner, V. Vuletić, and M. D. Lukin, Dispersive optical systems for scalable Raman driving of hyperfine qubits, Phys. Rev. A 105, 032618 (2022).
P. O. Schmidt, T. Rosenband, C. Langer, W. M. Itano, J. C. Bergquist, and D. J. Wineland, Spectroscopy using quantum logic, Science 309, 749 (2005).
P. Micke, T. Leopold, S. A. King, E. Benkler, L. J. Spieß, L. Schmöger, M. Schwarz, J. R. Crespo López-Urrutia, and P. O. Schmidt, Coherent laser spectroscopy of highly charged ions using quantum logic, Nature (London) 578, 60 (2020).
Y. Shigekawa, A. Yamaguchi, K. Tokoi, N. Sato, H. Kikunaga, K. Shirasaki, Y. Kasamatsu, M. Wada, and H. Haba, Lifetime of the singly charged ${}^{229}{Th}$ nuclear isomer, Nat. Phys. 22, 832 (2026) .
P. V. Bilous, H. Bekker, J. C. Berengut, B. Seiferle, L. von der Wense, P. G. Thirolf, T. Pfeifer, J. R. C. López-Urrutia, and A. Pálffy, Electronic bridge excitation in highly charged ${}^{229}{Th}$ ions, Phys. Rev. Lett. 124, 192502 (2020).
S. G. Porsev, C. Cheung, and M. S. Safronova, Low-lying energy levels of ${}^{229}{Th}^{35 +}$ and the electronic bridge process, Quantum Sci. Technol. 6, 034014 (2021).
F. F. Karpeshin, S. Wycech, I. M. Band, M. B. Trzhaskovskaya, M. Pfützner, and J. Żylicz, Rates of transitions between the hyperfine-splitting components of the ground-state and the 3.5 eV isomer in ${}^{229}{Th}^{89 +}$ , Phys. Rev. C 57, 3085 (1998).
K. Pachucki, S. Wycech, J. Żylicz, and M. Pfützner, Nuclear-spin mixing oscillations in ${}^{229}{Th}^{89 +}$ , Phys. Rev. C 64, 064301 (2001).
S. S. Maurya, V. Lal, J. Tiedau, M. Okhapkin, and E. Peik, J_0_clock_Th(2p)_Maurya_2026, Zenodo, 2026, https://doi.org/10.5281/zenodo.21266298.
