Site-selective preparation of two-dimensional dipolar quantum gases in an optical beat-note lattice

Niclas Höllrigl1,2, Marian Kreyer1, Rudolf Grimm1,2, and Emil Kirilov1,2,*

  • *Contact author: emil.kirilov@uibk.ac.at
PDF

Phys. Rev. A 114, 023322 – Published 24 August, 2026

DOI: https://doi.org/10.1103/8tph-r9fm

Abstract

High-resolution microscopy of two-dimensional dipolar quantum gases requires selecting individual atomic layers, a task complicated for strongly magnetic lanthanide atoms by the limited applicability of standard magnetic-gradient techniques. We present an all-optical method for the deterministic spatial selection of single- and bilayer samples of cold dipolar atoms using spatially selective parametric heating within a beat-note superlattice. By utilizing a high-resolution microscope objective as a common retroreflector for both optical frequency components, the lattice planes are passively stabilized. This renders their positions exceptionally robust against experimental drifts and structure-borne vibrations, even eliminating the need for active laser stabilization over millimeter-scale separations from the reflecting surface. We validate this approach by demonstrating the robust isolation of one or two atomic layers in precise coincidence with the focal plane of our objective. This enables future single-atom-resolved studies of long-range interacting systems.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (46)

  1. V. L. Berezinskii, Destruction of long-range order in one-dimensional and two-dimensional systems having a continuous symmetry group I. Classical systems, Sov. Phys. JETP 32, 493 (1971).
  2. J. M. Kosterlitz and D. J. Thouless, Ordering, metastability and phase transitions in two-dimensional systems, J. Phys. C: Solid State Phys. 6, 1181 (1973).
  3. B. C. Mulkerin, R. M. W. van Bijnen, D. H. J. O'Dell, A. M. Martin, and N. G. Parker, Anisotropic and long-range vortex interactions in two-dimensional dipolar Bose gases, Phys. Rev. Lett. 111, 170402 (2013).
  4. C. Lagoin, U. Bhattacharya, T. Grass, R. W. Chhajlany, T. Salamon, K. Baldwin, L. Pfeiffer, M. Lewenstein, M. Holzmann, and F. Dubin, Extended Bose-Hubbard model with dipolar excitons, Nature (London) 609, 485 (2022).
  5. L. Su, A. Douglas, M. Szurek, R. Groth, S. F. Ozturk, A. Krahn, A. H. Hébert, G. A. Phelps, S. Ebadi, S. Dickerson, F. Ferlaino, O. Marković, and M. Greiner, Dipolar quantum solids emerging in a Hubbard quantum simulator, Nature (London) 622, 724 (2023).
  6. H. Korbmacher, P. Sierant, W. Li, X. Deng, J. Zakrzewski, and L. Santos, Lattice control of nonergodicity in a polar lattice gas, Phys. Rev. A 107, 013301 (2023).
  7. M. Łącki, H. Korbmacher, G. A. Domínguez-Castro, J. Zakrzewski, and L. Santos, Ground states of one-dimensional dipolar lattice bosons at unit filling, Phys. Rev. B 109, 125104 (2024).
  8. C. Gross and W. S. Bakr, Quantum gas microscopy for single atom and spin detection, Nat. Phys. 17, 1316 (2021).
  9. A. Safavi-Naini, Ş. G. Söyler, G. Pupillo, H. R. Sadeghpour, and B. Capogrosso-Sansone, Quantum phases of dipolar bosons in bilayer geometry, New J. Phys. 15, 013036 (2013).
  10. F. Cinti, D.-W. Wang, and M. Boninsegni, Phases of dipolar bosons in a bilayer geometry, Phys. Rev. A 95, 023622 (2017).
  11. G. Guijarro, G. E. Astrakharchik, and J. Boronat, Ultradilute quantum liquid of dipolar atoms in a bilayer, Phys. Rev. Lett. 128, 063401 (2022).
  12. L. Du, P. Barral, M. Cantara, J. de Hond, Y.-K. Lu, and W. Ketterle, Atomic physics on a 50-nm scale: Realization of a bilayer system of dipolar atoms, Science 384, 546 (2024).
  13. L. Masi, T. Petrucciani, G. Ferioli, G. Semeghini, G. Modugno, M. Inguscio, and M. Fattori, Spatial Bloch oscillations of a quantum gas in a “beat-note” superlattice, Phys. Rev. Lett. 127, 020601 (2021).
  14. T. Petrucciani, A. Santoni, C. Mazzinghi, D. Trypogeorgos, F. Minardi, M. Fattori, and M. Modugno, Long-wavelength optical lattices from optical beatnotes: Theory and applications, Phys. Rev. A 112, 043323 (2025).
  15. H. Bender, P. Courteille, C. Zimmermann, and S. Slama, Towards surface quantum optics with Bose–Einstein condensates in evanescent waves, Appl. Phys. B 96, 275 (2009).
  16. J. I. Gillen, W. S. Bakr, A. Peng, P. Unterwaditzer, S. Fölling, and M. Greiner, Two-dimensional quantum gas in a hybrid surface trap, Phys. Rev. A 80, 021602(R) (2009).
  17. S. P. Rath, T. Yefsah, K. J. Günter, M. Cheneau, R. Desbuquois, M. Holzmann, W. Krauth, and J. Dalibard, Equilibrium state of a trapped two-dimensional Bose gas, Phys. Rev. A 82, 013609 (2010).
  18. P. Dyke, K. Fenech, T. Peppler, M. G. Lingham, S. Hoinka, W. Zhang, S.-G. Peng, B. Mulkerin, H. Hu, X.-J. Liu, and C. J. Vale, Criteria for two-dimensional kinematics in an interacting Fermi gas, Phys. Rev. A 93, 011603(R) (2016).
  19. J. F. Sherson, C. Weitenberg, M. Endres, M. Cheneau, I. Bloch, and S. Kuhr, Single-atom-resolved fluorescence imaging of an atomic Mott insulator, Nature (London) 467, 68 (2010).
  20. E. Haller, J. Hudson, A. Kelly, D. A. Cotta, B. Peaudecerf, G. D. Bruce, and S. Kuhr, Single-atom imaging of fermions in a quantum-gas microscope, Nat. Phys. 11, 738 (2015).
  21. B. Peaudecerf, M. Andia, M. Brown, E. Haller, and S. Kuhr, Microwave preparation of two-dimensional fermionic spin mixtures, New J. Phys. 21, 013020 (2019).
  22. L. Chomaz, I. Ferrier-Barbut, F. Ferlaino, B. Laburthe-Tolra, B. L. Lev, and T. Pfau, Dipolar physics: A review of experiments with magnetic quantum gases, Rep. Prog. Phys. 86 026401 (2023).
  23. R. A. Williams, J. D. Pillet, S. Al-Assam, B. Fletcher, M. Shotter, and C. J. Foot, Dynamic optical lattices: Two-dimensional rotating and accordion lattices for ultracold atoms, Opt. Express 16, 16977 (2008).
  24. J. L. Ville, T. Bienaimé, R. Saint-Jalm, L. Corman, M. Aidelsburger, L. Chomaz, K. Kleinlein, D. Perconte, S. Nascimbène, J. Dalibard, and J. Beugnon, Loading and compression of a single two-dimensional Bose gas in an optical accordion, Phys. Rev. A 95, 013632 (2017).
  25. A. P. Kazantsev and I. V. Krasnov, Rectification of the gradient force of resonant radiation pressure, JETP Lett. 46, 332 (1987).
  26. V. S. Voitsekhovich, M. V. Danileiko, A. M. Negriiko, V. I. Romanenko, and L. P. Yatsenko, Light pressure on atoms in on-coming amplitude-modulated waves, Zh. Tekh. Phys. 58, 1174 (1988).
  27. V. S. Voitsekhovich, M. V. Danileiko, A. M. Negriiko, V. I. Romanenko, and L. P. Yatsenko, Observation of a stimulated radiation pressure of amplitude-modulated light on atoms, JETP Lett. 49, 161 (1989).
  28. A. P. Kazantsev and I. V. Krasnov, Rectification effect of a radiation force, J. Opt. Soc. Am. B 6, 2140 (1989).
  29. R. Grimm, Y. B. Ovchinnikov, A. I. Sidorov, and V. S. Letokhov, Observation of a strong rectified dipole force in a bichromatic standing light wave, Phys. Rev. Lett. 65, 1415 (1990).
  30. R. Grimm, J. Söding, and Y. B. Ovchinnikov, Coherent beam splitter for atoms based on a bichromatic standing light wave, Opt. Lett. 19, 658 (1994).
  31. J. Söding, R. Grimm, Y. B. Ovchinnikov, P. Bouyer, and C. Salomon, Short-distance atomic beam deceleration with a stimulated light force, Phys. Rev. Lett. 78, 1420 (1997).
  32. H. Metcalf, Colloquium: Strong optical forces on atoms in multifrequency light, Rev. Mod. Phys. 89, 041001 (2017).
  33. R. Grimm, J. Söding, and Y. B. Ovchinnikov, Trapping atoms by rectified forces in bichromatic optical superlattices, JETP Lett. 61, 367 (1995).
  34. A. Görlitz, T. Kinoshita, T. W. Hänsch, and A. Hemmerich, Realization of bichromatic optical superlattices, Phys. Rev. A 64, 011401(R) (2001).
  35. G. Anich, N. Höllrigl, M. Kreyer, R. Grimm, and E. Kirilov, Comprehensive characterization of an apparatus for cold electromagnetic dysprosium dipoles, Phys. Rev. A 110, 023311 (2024).
  36. T. Maier, H. Kadau, M. Schmitt, A. Griesmaier, and T. Pfau, Narrow-line magneto-optical trap for dysprosium atoms, Opt. Lett. 39, 3138 (2014).
  37. F. Mühlbauer, N. Petersen, C. Baumgärtner, L. Maske, and P. Windpassinger, Systematic optimization of laser cooling of dysprosium, Appl. Phys. B 124, 120 (2018).
  38. S. Tung, G. Lamporesi, D. Lobser, L. Xia, and E. A. Cornell, Observation of the presuperfluid regime in a two-dimensional Bose gas, Phys. Rev. Lett. 105, 230408 (2010).
  39. P. A. Murthy, D. Kedar, T. Lompe, M. Neidig, M. G. Ries, A. N. Wenz, G. Zürn, and S. Jochim, Matter-wave Fourier optics with a strongly interacting two-dimensional Fermi gas, Phys. Rev. A 90, 043611 (2014).
  40. L. Asteria, H. P. Zahn, M. N. Kosch, K. Sengstock, and C. Weitenberg, Quantum gas magnifier for sub-lattice-resolved imaging of 3D quantum systems, Nature (London) 599, 571 (2021).
  41. S. Brandstetter, C. Heintze, P. Hill, P. M. Preiss, M. Gałka, and S. Jochim, Magnifying the wave function of interacting fermionic atoms, Phys. Rev. Lett. 135, 103401 (2025).
  42. M. Sohmen, M. J. Mark, M. Greiner, and F. Ferlaino, A ship-in-a-bottle quantum gas microscope for magnetic mixtures, SciPost Phys. 15, 182 (2023).
  43. S. Dettmer, D. Hellweg, P. Ryytty, J. J. Arlt, W. Ertmer, K. Sengstock, D. S. Petrov, G. V. Shlyapnikov, H. Kreutzmann, L. Santos, and M. Lewenstein, Observation of phase fluctuations in elongated Bose-Einstein condensates, Phys. Rev. Lett. 87, 160406 (2001).
  44. C. I. Sukenik, M. G. Boshier, D. Cho, V. Sandoghdar, and E. A. Hinds, Measurement of the Casimir-Polder force, Phys. Rev. Lett. 70, 560 (1993).
  45. H. Bender, P. W. Courteille, C. Marzok, C. Zimmermann, and S. Slama, Direct measurement of intermediate-range Casimir-Polder potentials, Phys. Rev. Lett. 104, 083201 (2010).
  46. Universität Innsbruck, Data Repository, https://doi.org/10.48323/0rzbb-wzw20.
