Double and triple photoionization of the Be-like B+ ion: Role of double-K-shell-vacancy states

A. Müller*, P.-M. Hillenbrand, S.-X. Wang, and S. Schippers

S. Reinwardt and M. Martins

J. Seltmann

F. Trinter

I. Bray and D. V. Fursa

A. S. Kheifets

  • *Contact author: Alfred.Mueller@physik.jlug.de
PDF

Phys. Rev. A 114, 023110 – Published 28 August, 2026

DOI: https://doi.org/10.1103/6hs5-lvwn

Abstract

Double and triple photoionization of Be-like B+ ions have been studied in the photon-energy range from approximately 250 to 1300 eV. The method of merged photon and ion beams was employed and calculations were performed in support of the experiments making use of different theoretical approaches. The cross section σ13 for net double ionization in the investigated photon-energy range is dominated by direct removal of one K-shell electron and subsequent single-Auger decay. K-shell ionization is described very well by theory. Accordingly, measured yields of B3+ photoproducts were normalized to theory to obtain absolute cross sections σ13. Aside from the process of direct single ionization plus autoionization, σ13 additionally contains contributions from photoexcited double-K-shell-vacancy B+ resonances, from direct double L-shell ionization, and from direct double ionization involving one L-shell and one K-shell electron. We show that, apart from single K-shell ionization with subsequent Auger decay, all these processes are of minor importance for σ13. Nevertheless, the sensitivity of our experiment allowed us to observe the 2s22p3sP11 double-K-shell-vacancy resonance and to determine its energy, width, strength, and asymmetry parameter. Relativistic Hartree-Fock theory was employed to characterize the role of such resonances in σ13. The cross section σ14 for net triple ionization of B+ is expected to arise primarily from direct double K-shell ionization and subsequent single-Auger decay. The experimental cross section is found to be larger than theoretical predictions. Possible additional contributions to σ14 such as K-shell ionization with accompanying K-shell excitation and subsequent Auger decay are discussed, as is the influence of metastable ions in the primary B+ ion beam.

View figure in article

Physics Subject Headings (PhySH)

Article Text

References (46)

  1. A. Müller, P.-M. Hillenbrand, S.-X. Wang, S. Schippers, E. Lindroth, F. Trinter, J. Seltmann, S. Reinwardt, M. Martins, A. S. Kheifets, and I. Bray, Double-K-hole resonances in single photoionization of He-like B3+ ions, Phys. Rev. A 110, 062802 (2024).
  2. A. Müller, P.-M. Hillenbrand, S.-X. Wang, S. Schippers, I. Bray, A. S. Kheifets, E. Lindroth, S. Reinwardt, M. Martins, J. Seltmann, and F. Trinter, Direct double ionization of the He-like B3+ ion by a single photon, Phys. Rev. A 111, 023115 (2025).
  3. A. Müller, P.-M. Hillenbrand, S.-X. Wang, S. Schippers, S. Reinwardt, M. Martins, J. Seltmann, F. Trinter, I. Bray, D. V. Fursa, and A. S. Kheifets, Single and double photoionization of the Li-like B2+ ion: Strong ionization-excitation contributions, Phys. Rev. A 111, 053108 (2025).
  4. S. Schippers, A. Müller, B. M. McLaughlin, A. Aguilar, C. Cisneros, E. Emmons, M. F. Gharaibeh, and R. A. Phaneuf, Photoionization studies of the B+ valence shell: Experiment and theory, J. Phys. B: At. Mol. Opt. Phys. 36, 3371 (2003).
  5. A. Müller, S. Schippers, R. A. Phaneuf, S. W. J. Scully, A. Aguilar, C. Cisneros, M. F. Gharaibeh, A. S. Schlachter, and B. M. McLaughlin, K-shell photoionization of Be-like boron (B+) ions: Experiment and theory, J. Phys. B: At. Mol. Opt. Phys. 47, 135201 (2014).
  6. A. Müller, S. Schippers, R. A. Phaneuf, S. W. J. Scully, A. Aguilar, C. Cisneros, M. F. Gharaibeh, A. S. Schlachter, and B. M. McLaughlin, K-shell photoionization of ground-state Li-like boron ions [B2+]: Experiment and theory, J. Phys. B: At. Mol. Opt. Phys. 43, 135602 (2010).
  7. J. Viefhaus, F. Scholz, S. Deinert, L. Glaser, M. Ilchen, J. Seltmann, P. Walter, and F. Siewert, The variable polarization XUV beamline P04 at PETRA III: Optics, mechanics and their performance, Nucl. Instrum. Methods Phys. Res. Sect. A 710, 151 (2013).
  8. C. G. Schroer, H.-C. Wille, O. H. Seeck, K. Bagschik, H. Schulte-Schrepping, M. Tischer, H. Graafsma, W. Laasch, K. Baev, S. Klumpp, R. Bartolini, H. Reichert, W. Leemans, and E. Weckert, The synchrotron radiation source PETRA III and its future ultra-low-emittance upgrade PETRA IV, Eur. Phys. J. Plus 137, 1312 (2022).
  9. S. Schippers, T. Buhr, A. Borovik, Jr., K. Holste, A. Perry-Sassmannshausen, K. Mertens, S. Reinwardt, M. Martins, S. Klumpp, K. Schubert, S. Bari, R. Beerwerth, S. Fritzsche, S. Ricz, J. Hellhund, and A. Müller, The photon-ion merged-beams experiment PIPE at PETRA III - The first five years, X-Ray Spectrom. 49, 11 (2020).
  10. R. A. Phaneuf, C. C. Havener, G. H. Dunn, and A. Müller, Merged-beams experiments in atomic and molecular physics, Rep. Prog. Phys. 62, 1143 (1999).
  11. S. Schippers, S. Ricz, T. Buhr, A. Borovik, Jr., J. Hellhund, K. Holste, K. Huber, H.-J. Schäfer, D. Schury, S. Klumpp, K. Mertens, M. Martins, R. Flesch, G. Ulrich, E. Rühl, T. Jahnke, J. Lower, D. Metz, L. P. H. Schmidt, M. Schöffler, et al., Absolute cross sections for photoionization of Xeq+ ions (1≤q≤5) at the 3d ionization threshold, J. Phys. B: At. Mol. Opt. Phys. 47, 115602 (2014).
  12. A. Müller, D. Bernhardt, A. Borovik, Jr., T. Buhr, J. Hellhund, K. Holste, A. L. D. Kilcoyne, S. Klumpp, M. Martins, S. Ricz, J. Seltmann, J. Viefhaus, and S. Schippers, Photoionization of Ne atoms and Ne+ ions near the K edge: Precision spectroscopy and absolute cross-sections, Astrophys. J. 836, 166 (2017).
  13. M. O. Krause, Atomic radiative and radiationless yields for K and L shells, J. Phys. Chem. Ref. Data 8, 307 (1979).
  14. A. Kramida, Y. Ralchenko, J. Reader, and NIST ASD Team, NIST Atomic Spectra Database (version 5.12), National Institute of Standards and Technology, Gaithersburg, MD (2024), http://physics.nist.gov/asd.
  15. D. A. Verner, D. G. Yakovlev, I. M. Band, and M. B. Trzhaskovskaya, Subshell photoionization cross sections and ionization energies of atoms and ions from He to Zn, At. Data Nucl. Data Tables 55, 233 (1993).
  16. A. S. Kheifets, Dynamic scaling of photo-double-ionization to electron impact, Phys. Rev. A 101, 032701 (2020).
  17. M. W. McIntyre, A. J. Kinnen, and M. P. Scott, Photo-double-ionization of the He and Be isoelectronic sequences within an intermediate-energy R-matrix framework, Phys. Rev. A 88, 053413 (2013).
  18. M. W. McIntyre and M. P. Scott, Photo-double-ionization of He-like and Be-like systems in excited states within an intermediate-energy R-matrix framework, Phys. Rev. A 89, 043418 (2014).
  19. M. P. Scott, A. J. Kinnen, and M. W. McIntyre, Photon collisions with atoms and ions within an intermediate-energy R-matrix framework, Phys. Rev. A 86, 032707 (2012).
  20. A. S. Kheifets and I. Bray, Calculation of double photoionization of helium using the convergent close-coupling method, Phys. Rev. A 54, R995(R) (1996).
  21. A. S. Kheifets and I. Bray, Photoionization with excitation and double photoionization of the helium isoelectronic sequence, Phys. Rev. A 58, 4501 (1998).
  22. I. Bray, D. V. Fursa, A. S. Kheifets, and A. T. Stelbovics, Electrons and photons colliding with atoms: Development and application of the convergent close-coupling method, J. Phys. B: At. Mol. Opt. Phys. 35, R117 (2002).
  23. A. S. Kheifets, D. V. Fursa, and I. Bray, Two-electron photoionization of ground-state lithium, Phys. Rev. A 80, 063413 (2009).
  24. A. S. Kheifets, D. V. Fursa, I. Bray, J. Colgan, and M. S. Pindzola, Differential cross sections of double photoionization of lithium, Phys. Rev. A 82, 023403 (2010).
  25. A. S. Kheifets, D. V. Fursa, C. W. Hines, I. Bray, J. Colgan, and M. S. Pindzola, Spin effects in double photoionization of lithium, Phys. Rev. A 81, 023418 (2010).
  26. A. W. Bray, A. S. Kheifets, and I. Bray, Calculation of atomic photoionization using the nonsingular convergent close-coupling method, Phys. Rev. A 95, 053405 (2017).
  27. A. Müller, A. S. Kheifets, I. Bray, and D. V. Fursa, Photoionization of the Li atom: Convergent-close-coupling calculations with a focus on two-electron removal, Phys. Rev. A 113, 033105 (2026).
  28. K. G. Dyall, I. P. Grant, C. T. Johnson, F. A. Parpia, and E. P. Plummer, GRASP: A general-purpose relativistic atomic structure program, Comput. Phys. Commun. 55, 425 (1989).
  29. A. Müller, A. L. D. Kilcoyne, R. A. Phaneuf, K. Holste, S. Schippers, and A. S. Kheifets, Direct double ionization of the Ar+M shell by a single photon, Phys. Rev. A 103, L031101 (2021).
  30. A. Müller, M. Martins, A. Borovik, Jr., T. Buhr, A. Perry-Sassmannshausen, S. Reinwardt, F. Trinter, S. Schippers, S. Fritzsche, and A. S. Kheifets, Role of L-shell single and double core-hole production and decay in m-fold (1≤m≤6) photoionization of the Ar+ ion, Phys. Rev. A 104, 033105 (2021).
  31. M. Y. Amusia, Atomic photoeffect, in Physics of Atoms and Molecules, edited by K. T. Taylor (Plenum Press, New York, 1990).
  32. M. Y. Amusia, Random phase approximation: From giant to intra-doublet resonances, Radiat. Phys. Chem. 70, 237 (2004).
  33. R. D. Cowan, The Theory of Atomic Structure and Spectra (University of California, Berkeley, 1981).
  34. R. F. Reilman and S. T. Manson, Photoabsorption cross sections for positive atomic ions with Z≤30, Astrophys. J. Suppl. Ser. 40, 815 (1979).
  35. S. Hasegawa, F. Yoshida, L. Matsuoka, F. Koike, S. Fritzsche, S. Obara, Y. Azuma, and T. Nagata, Photoexcitation of K-shell and L-shell hollow beryllium, Phys. Rev. Lett. 97, 023001 (2006).
  36. M. Martins, Photoionization of open-shell atoms: The chlorine 2p excitation, J. Phys. B: At. Mol. Opt. Phys. 34, 1321 (2001).
  37. U. Fano, Effects of configuration interaction on intensities and phase shifts, Phys. Rev. 124, 1866 (1961).
  38. S. Schippers, Analytical expression for the convolution of a Fano line profile with a Gaussian, J. Quant. Spectrosc. Radiat. Transfer 219, 33 (2018).
  39. R. Wehlitz, M.-T. Huang, B. D. DePaola, J. C. Levin, I. A. Sellin, T. Nagata, J. W. Cooper, and Y. Azuma, Triple photoionization of lithium, Phys. Rev. Lett. 81, 1813 (1998).
  40. A. Müller, A. Borovik, Jr., T. Buhr, J. Hellhund, K. Holste, A. L. D. Kilcoyne, S. Klumpp, M. Martins, S. Ricz, J. Viefhaus, and S. Schippers, Observation of a four-electron Auger process in near-K-edge photoionization of singly charged carbon ions, Phys. Rev. Lett. 114, 013002 (2015).
  41. T. Pattard, A shape function for single-photon multiple ionization cross sections, J. Phys. B: At. Mol. Opt. Phys. 35, L207 (2002).
  42. A. S. Kheifets, I. Bray, and J. Hoszowska, K-shell double photoionization of Be, Mg, and Ca, Phys. Rev. A 79, 042504 (2009).
  43. V. A. Yerokhin, A. Surzhykov, and S. Fritzsche, Relativistic calculations of double K-shell-photoionization cross sections for neutral medium-Z atoms, Phys. Rev. A 90, 063422 (2014).
  44. S. H. Southworth, S. Li, D. Koulentianos, G. Doumy, L. Young, D. A. Walko, R. Püttner, D. Céolin, R. Guillemin, I. Ismail, O. Travnikova, M. N. Piancastelli, M. Simon, S. T. Manson, and T. W. Gorczyca, Energy variation of double K-shell photoionization of Ne, Phys. Rev. A 107, 023110 (2023).
  45. M. F. Gu, The flexible atomic code, Can. J. Phys. 86, 675 (2008).
  46. A. Müller, A. Borovik, Jr., K. Huber, S. Schippers, D. V. Fursa, and I. Bray, Double-K-vacancy states in electron-impact single ionization of metastable two-electron N5+(1s2s3S1) ions, Phys. Rev. A 90, 010701(R) (2014).
